| Motherboard Basic Info | |
| Supported CPU | Intel® Core™ i7 LGA 1156 Processor Intel® Core™ i5 LGA 1156 Processor Intel® Core™ i3 LGA 1156 Processor Intel® Pentium® LGA 1156 Processor Maximum CPU TDP (Thermal Design Power) : 95Watt |
| External Features | |
| I/O Port | 2 x USB 2.0 Header 4 x SATA II Connector (3Gb/s ) 1 x IDE Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-Out Header 1 x CPU Fan Connector 1 x System Fan Connector 1 x CIR Header 1 x COM Port Header 1 x Printer Port Header |
| Physical Specification | |
| Dimension (L x W x H) | Micro ATX Form Factor Dimension: 24.4cm X 20cm ( W x L ) |
| Motherboard Memory Info | |
| Supported Memory | Support Dual Channel DDR3 1600(OC)/1333/1066/800 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 8GB Memory |
| Connector & Ports (MB) | |
| USB (s) | 4 x USB 2.0 Port 2 x USB 2.0 Header |
| LAN Port (s) | Realtek RTL8111DL - 10/100/1000 Controller |
| Audio | Realtek ALC662 6-Channel HD Audio |
| Warranty Information | |
| Manufacturing Warranty | 01 Years Of Warranty |
Speed H55-S2H Micro ATX Motherboard
Supports the Intel Core i7 / i5 / i3 / Pentium Processors in the LGA1156 Package
Intel H55 single chip architecture
5 Phases Power Design
Support 2-DIMM 1600(OC)/1333/1066
Integrated HDMI/DVI interface with HDCP Supporting all HD formats including 720P, 1080i, 1080P. ( Required processors with Intel HD Graphics )
CPU integrated Graphics performance tunable via BIOS
Optimized to deliver full windows 7 Experience
Supports BIO-Remote 2 Technology
Supports Charger Booster Technology
The Speed H55-S2H Micro ATX Motherboard is In Stock now. You can buy the Speed H55-S2H Micro ATX Motherboard at the best price from our website or visit any of our showrooms When the product is available.
